Features:
Made in the USA
Designed and constructed domestically
Slim 24 inch width
Apartment-sized width offers all the functionality you need in a smaller footprint
24 inch depth
Shallower fit is ideal for L-shaped and galley kitchens
Four open burners
9000 BTU burners with built-in enamel grates to meet most cooking needs
Natural gas design
Set for use with natural gas connection. To convert for propane use, add Kit LP
Electronic ignition
Spark ignition system with a pre-installed 115V 3-prong cord
Oven window and interior lighting
Door includes a window and exterior on/off rocker light switch, making it easier to monitor your cooking without opening the door
Deluxe backguard
8″ high backguard to protect wall from back splashes
Digital clock and timer
Backguard includes time readout
Upfront oven/burner controls
Push-to-turn knobs offer easier, safer access, preventing users from reaching over hot burners to adjust
Recessed oven door
Smart design limits the depth and protects adjacent cabinets
Adjustable oven racks
Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
Broiler compartment
Lower drop-down compartment for separate broiling with even heat distribution
Porcelain and steel construction
Lasting durability with solid construction inside and out designed to hold up to everyday kitchen use
Removable oven door and range top
White porcelain oven door and top can be removed for easier cleaning
Anti-tip bracket included
Included for user installation to help prevent tipping
Broiler pan included
Two-piece porcelain broiler tray with grease well
White exterior finish
Classic design in a clean white finish to match any kitchen
Specifications | |
| Brand | Summit |
| Appliance Category | Range |
Appearance | |
| Color | White |
| Color Family | White |
| Design Style | Standard |
Dimensions | |
| Exterior Width | 24" |
| Width | 24" |
| Depth | 24" |
| Height | 44" |
Fuel Type | |
| Fuel Type | Gas |
| Gas Type | Natural Gas |
Style | |
| Style | Freestanding |
Capacity | |
| Oven Total Capacity (cu. ft.) | 2.92 |
Cooking Surface | |
| Burner/Element Type | Open Burner |
| Number of Burners/Elements | 4 |
| Grill | No |
| Griddle | No |
| French Top | No |
| Highest Burner Output | 9000 BTU |
| Burner/Element Output N1 | 9000 BTU |
| Burner/Element Output N2 | 9000 BTU |
| Burner/Element Output N3 | 9000 BTU |
| Burner/Element Output N4 | 9000 BTU |
Oven | |
| Oven Control Type | Knobs |
| Double Oven | No |
| Viewing Window | Yes |
| Oven Cleaning Type | Manual Clean |
| Interior Oven Light | Yes |
| Interior Width | 19" |
| Interior Height | 14" |
| Interior Depth | 19" |
| Oven Racks | 2 |
| Oven BTUs | 16000 BTU |
Technical Details | |
| Voltage | 115 |
| Amps | 15 |
| Frequency | 60 Hz. |
Certifications | |
| ADA Compliant | No |
Features | |
| Convection | No |
| Sabbath Mode | No |
| Cooktop Control Type | Knobs |
| Removable Door | Yes |
| Drawer | Broiler |
| Timer | Yes |
| Temperature Probe | No |
| Continuous Grates | No |
| Proofing | No |
| Digital Clock | Yes |
| Digital Temperature Display | No |
| Delay Bake | No |
| Downdraft | No |
| Gas Conversion Kit Included | Sold Separately |
| LP Convertible | Yes |
