Features:
Captur™ System
The Captur™ system’s advanced blower/wheel design features a centric inlet to remove smoke and odor faster.
300 CFM
Two-speed blower control exhausts at 300 MAX Blower CFM
1.5 Sones
Forward placement and smooth-flow blower wheel design ensure quiet, 1.5 sones operation at normal speed
Rocker Switches
Hidden on/off rocker switches control blower speeds and light levels
Micro-Mesh Filters
Dishwasher-safe, micro-mesh filters provide efficient grease removal
EZ1 Brackets
EZ1 brackets enable single-person installation in less than half the time of traditional methods
ADA Capable (Wall Switch Sold Separately)
ADA compliant, remote operation is possible using a standard UL approved wall switch.
EZ1 System
EZ1 system enables easy single-person installation in up to half the time of traditional methods
LED Lighting
Two-level, LED bulbs flood the cooktop and surrounding area with generous illumination.
Non-Duct Capable
Non-duct capable with use of charcoal filters, sold separately. Hidden louvers on top of hood exhaust away from cabinetry
Additional Features:
- 7″ Round Duct
- Horizontal/Vertical Duct Direction
- HVI Certified
- UL Listed
1 Year Limited Warranty
Specifications | |
| Brand | Broan |
| Series | Alta |
Appearance | |
| Color | White |
| Color Family | White |
Dimensions | |
| Exterior Width | 30" |
| Width | 29 7/8" |
| Depth | 22" |
| Height | 5" |
Style | |
| Style | Standard Hood |
| Type | Hood |
| Mounting Type | Under Cabinet |
| Glass Canopy | No |
| Fan | Yes |
Technical Details | |
| Voltage | 120 |
| Amps | 1.4 |
| Duct Type | Both |
| Number of Light Bulbs | 2 |
| Duct Diameter | 7" |
| Duct Length | 3 1/4" |
| Duct Width | 10" |
| Frequency | 60 Hz. |
| Vent Location | Top or Rear |
Certifications | |
| UL Listed | Yes |
Features | |
| Convertible Ducting | Yes |
| CFM | 300 |
| Filter Type | Mesh |
| Venting Type | Convertible |
| Blower Type | Internal |
| Light Bulb Type | LED |
| Number of Fan Speeds | 2 |
| Light | Yes |
| Recirculating Kit | Sold Separately |
| Watts | 168 |
